Electron Microscopy

  • Talos F 200i
  • Quanta 250
  • 15x15 array
  • emitter
  • Cubes
  • Cubes
  • Fecl3
  • Solgel

The department houses both a transmission (TEM) and scanning electron microscope (SEM). Using electrons with much smaller wavelengths than visible light, electron microscopes are capable of resolving smaller features than light microscopes, in the nanometer to angstrom ranges depending on the configuration of the electron microscope. In SEM a beam of electrons (~1-30 kV in energy) is scanned across the surface of the sample and information collected at each point (pixel) of the sample. This gives topographical and elemental information (when coupled with energy dispersive X-ray spectroscopy) from the sample at relatively low to moderate magnifications (25x - ~100,000x) By contrast, a TEM functions similarly to a light microscope where the whole area of interest is illuminated by the beam and the image is magnified by lenses to be projected on a camera. TEM utilizes higher energy electrons (~40-200 kV in energy) than SEM which allows much higher magnifications to be achieved (up to ~ 1,000,000x) but also requires very thin samples (for electron transparency). Scanning coils incorporated in the lens column of the TEM allows even greater magnifications (~10,000,000x) in scanning transmission electron microscopy (STEM) mode for very high-resolution work. The addition of an energy dispersive X-ray detector (EDS) affords elemental characterization in both the SEM and STEM.

Our Talos F200i scanning TEM has multiple sample holders, single and double tilt for routine imaging and diffraction, a high visibility tomography holder for 3D volume reconstructions, and a high tilt cryo-holder for biological and sensitive samples. The Talos is equipped with a 16-megapixel camera with a capability of 40 frames per second for dynamic experiments. In STEM mode various angular distributions of scattered electrons are collected on the on-axis brightfield/segmented dark field detectors and high angle annular dark field detector. A Bruker Quantax energy dispersive spectrometer is used for elemental characterization of samples in scanning mode. Samples need to be thinned to thicknesses around 100 nm before imaging in the TEM.

Our Quanta 250 environmental SEM is equipped with detectors for both secondary and backscattered electrons at a range of vacuum pressures, with an EDAX Element EDS detector for elemental X-ray characterization of samples. Samples should be conductive or can be coated with a conductive layer. However, the use of a variable pressure chamber allows for the imaging of non-conductive samples as well.
